Compact structure, high reliability, high power performance and excellent economy.
Power range: 132-180 kW. Euro II/III/IV/V emission standards. Maximum torque 900N.m at engine speed 1,200-1,600rpm. Engine weight: 620kg. Application: medium- and heavy-duty trucks.
| Maximum Power | 180 kW |
| Minimum Power | 132 kW |
| Maximum Torque / Speed | 900/（1200-1600） N·m / r/min |
| Emissions | Euro II/III/IV/V |
| Series | WP6 |
| Fuel | Diesel |
| EngineType | Inline 6-cylinder, four-stroke engine |
| Cylinder Number | 6 |
| Valve Number | 2 |
| Bore | 105 mm |
| Stroke | 130 mm |
| Displacement | 6.75 L |
| Aspiration | Turbocharged and intercooled |
| Compression Ratio | 18:1 |
| Combustion System | Mechanical pump/Electronically controlled high-pressure common-rail |
| Length | 1256 mm |
| Width | 572 mm |
| Height | 972 mm |
| Weight - Net Dry (Basic Operating Engine Without Optional Attachments) | 620±50 kg |
Remarks: Product parameters and pictures are for reference only; subject to change without notice.
